Rubber (DK - Conductive) Casters
SERIES: CST-F-CR

CONSTRUCTED OF HIGH-GRADE THERMOPLASTIC RUBBER (TPR). CHEMICALLY BONDED TO CORE. PROTECTS AGAINST ELECTROSTATIC BUILD-UP AND DISCHARGE THAT CAN BE GENERATED BY TRANSPORT. IDEAL FOR ELECTRONIC COMPANIES, MEDICAL ENGINEERING, AND OTHER ENVIRONMENTS WHERE STATIC BUILD UP IS A CONCERN. GRAY TREAD COLOR. 65 SHORE A. WHEEL CORE IS CONSTRUCTED OF POLYOLEFIN.

  • OHMIC RESISTANCE 10^3(OMEGA) EXCEED THE REQUIREMENTS OF FEDERAL STANDARD FF-C-88C
  • NON-MARKING
  • SMOOTH RIDE PERFORMANCE
  • QUIET OPERATION
  • EXCEPTIONAL FLOOR PRESERVATION
  • RESISTS MOSTS SOLVENTS, OILS, GREASE, AND WATER
  • PREMIUM PRECISION BALL BEARINGS

CONSTRUCTED OF HIGH-GRADE THERMOPLASTIC RUBBER (TPR). CHEMICALLY BONDED TO CORE. PROTECTS AGAINST ELECTROSTATIC BUILD-UP AND DISCHARGE THAT CAN BE GENERATED BY TRANSPORT. IDEAL FOR ELECTRONIC COMPANIES, MEDICAL ENGINEERING, AND OTHER ENVIRONMENTS WHERE STATIC BUILD UP IS A CONCERN. GRAY TREAD COLOR. 65 SHORE A. WHEEL CORE IS CONSTRUCTED OF POLYOLEFIN.

  • OHMIC RESISTANCE 10^3(OMEGA) EXCEED THE REQUIREMENTS OF FEDERAL STANDARD FF-C-88C
  • NON-MARKING
  • SMOOTH RIDE PERFORMANCE
  • QUIET OPERATION
  • EXCEPTIONAL FLOOR PRESERVATION
  • RESISTS MOSTS SOLVENTS, OILS, GREASE, AND WATER
  • PREMIUM PRECISION BALL BEARINGS

Other "Go-To" Casters

 Upgraded Kingpinless Glass Filled Nylon (RX) Casters Upgraded Glass Filled Nylon, Light Duty (RX) Casters Elastic Rubber (Blue) Casters Poly On Poly Casters (Orange)

Share This Page

How To Order

Model Number & Specs Table

All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.
Rubber (DK - Conductive) Casters
Model Image Caster
Size		 Type Capacity
(lbs)		 Overall
Height		 Top Plate
Size		 Net Wt.
(lbs)
CST-F-4X2CR-R 4X2 RIGID 450 5.5" 4 X 4 1/2 2.83
CST-F-5X2CR-R 5X2 RIGID 500 6.5" 4 X 4 1/2 3.18
CST-F-6X2CR-R 6X2 RIGID 600 7.5" 4 X 4 1/2 3.66
CST-F-8X2CR-R 8X2 RIGID 675 9.5" 4 X 4 1/2 4.46
CST-F-4X2CR-S 4X2 SWIVEL 450 5.5" 4 X 4 1/2 3.58
CST-F-5X2CR-S 5X2 SWIVEL 500 6.5" 4 X 4 1/2 3.95
CST-F-6X2CR-S 6X2 SWIVEL 600 7.5" 4 X 4 1/2 4.43
CST-F-8X2CR-S 8X2 SWIVEL 675 9.5" 4 X 4 1/2 5.27
CST-F-4X2CR-SWB 4X2 SWIVEL W/BRAKE 450 5.5" 4 X 4 1/2 3.93
CST-F-5X2CR-SWB 5X2 SWIVEL W/BRAKE 500 6.5" 4 X 4 1/2 4.2
CST-F-6X2CR-SWB 6X2 SWIVEL W/BRAKE 600 7.5" 4 X 4 1/2 4.83
CST-F-8X2CR-SWB 8X2 SWIVEL W/BRAKE 675 9.5" 4 X 4 1/2 5.72
CST-F-4X2CR-SWTB1 4X2 Swivel w/Total Brake 450 5.5" 4 X 4 1/2 4.095
CST-F-6X2CR-SWTB1 6X2 Swivel w/Total Brake 600 7.5" 4 X 4 1/2 5
CST-F-8X2CR-SWTB1 8X2 Swivel w/Total Brake 675 9.5" 4 X 4 1/2 5.9
CST-F-5X2CR-SWTB1 5X2 SWTB1 500 6.5" 4 X 4 1/2 4.5
