TMS-40-DC

Printer Friendly
Available
TMS-40-DC
TMS-40-DC TMS-40-DC TMS-40-DC TMS-40-DC TMS-40-DC

Steel Tilt Master Straddle DC Powered 12 Volt 4,000 Lb. Capacity Blue

The tilt master straddle lifts and positions filled tote boxes or baskets without the need of a fork truck or lift table using the newly designed heavy-duty tilt master. The tilter will function as transporters by moving completed products from work station to work station without waiting for a fork truck. This lift has a thin profile to allow the user to get as close to the load as possible. It also has a standard floor lock and rolls easily on the phenolic steering wheels. Lift is designed to be used with virtually any kind of container or pallet. The unit is powered by a DC electric motor that includes an on-board battery charger and battery charge indicator.

  • Folding ergonomic handle
  • Two rigid and two swivel casters provide smooth and efficient mobility
  • 90 Degrees tilt angle allows for better ergonomic access
  • Push button hand control for quick lifting and lowering
Assembled Wt.(lbs.): 926 Assembled Size: 57.25"W x 73.25"L x 29.25"H

Total Ship Wt.(lbs.): 998 (only 1 package) Package 1 Size: 64"W x 64"D x 34"H Color: Blue

Uniform Capacity (lb.): 4,000 Adjustable Fork Spacing (in.): 1/2 to 28-1/2 Straddle (in.): 49-5/16
Operator Reach (in.): 12-1/2 Fork Width (in.): 4 Fork Length (in.): 36
Rotated Height (in.): 72-1/8 Lowered Fork Height (in.): 3 Maximum Tilt Degree: 90
Power: 12V DC Wheel Diameter (in.): 8 Wheel Width (in.): 3
Wheel Type: Phenolic Folding Handle Length (in.): 20 Load Center (in.): 18
Level Height (in.): 29

Quickship Item?

Quickship Item

Can It Ship UPS/FedEx?


LTL - Must Go Truck

Image Gallery

PDF Documents

1 Year Limited Warranty

Details For Model: TMS-40-DC
Available
TMS-40-DC

Steel Tilt Master Straddle DC Powered 12 Volt 4,000 Lb. Capacity Blue

The tilt master straddle lifts and positions filled tote boxes or baskets without the need of a fork truck or lift table using the newly designed heavy-duty tilt master. The tilter will function as transporters by moving completed products from work station to work station without waiting for a fork truck. This lift has a thin profile to allow the user to get as close to the load as possible. It also has a standard floor lock and rolls easily on the phenolic steering wheels. Lift is designed to be used with virtually any kind of container or pallet. The unit is powered by a DC electric motor that includes an on-board battery charger and battery charge indicator.

  • Folding ergonomic handle
  • Two rigid and two swivel casters provide smooth and efficient mobility
  • 90 Degrees tilt angle allows for better ergonomic access
  • Push button hand control for quick lifting and lowering
Dimensions: 57.25"W x 73.25"L x 29.25"H Sell UOM: -- Color: Blue
Material: -- UPC: -- GTIN: --
Warranty: -- Shipping Weight: 998 Quickship Item? --
Can It Ship UPS? -- Option? -- Origin: --
Assembly: -- Packaging: -- Drawing Required? --
Uniform Capacity (lb.): 4,000 Adjustable Fork Spacing (in.): 1/2 to 28-1/2 Straddle (in.): 49-5/16
Operator Reach (in.): 12-1/2 Fork Width (in.): 4 Fork Length (in.): 36
Rotated Height (in.): 72-1/8 Lowered Fork Height (in.): 3 Maximum Tilt Degree: 90
Power: 12V DC Wheel Diameter (in.): 8 Wheel Width (in.): 3
Wheel Type: Phenolic Folding Handle Length (in.): 20 Load Center (in.): 18
Level Height (in.): 29
